Bộ phát wifi EnGenius EWS850-FIT

0 trên 5 dựa trên 2 đánh giá

(Có 0 đánh giá)

Mã sản phẩm: EWS850-FIT Tình trạng: In stock

Liên hệ báo giá: 0979.300.098

Thiết bị thu phát vô tuyến kèm phụ kiện Engenius EWS850-FIT
Chuyên dụng: WiFi Outdoor – IP67
Cloud Managed, 2×2 ax1800 Outdoor AP, external 5dBi SMA ant
1 x 10/100/1000/2500 BASE-T, PoE af/at (Maximum Power 15.9W), chịu nhiệt -20 ºC~60 ºC.

Description
Reviews (0)

Thông số kỹ thuật

Technical Specifications
Standards	802.11a/b/g/n/ac/ax
Antenna – 2.4GHz	5dBi
Antenna – 5GHz	5dBi
Physical Interfaces	1 x 10/100/1000/2500 BASE-T
LED indicators	1 x Power 1 x LAN 1 x 2.4 GHz 1 x 5 GHz
Power Source	PoE 802.3af/at
Maximum Power Consumption	15.9W
Wireless & Radio Specifications
Operating Frequency	Dual-Radio Concurrent 2.4 GHz & 5 GHz
Operation Modes	Managed mode: AP, AP Mesh, Mesh
Frequency Radio	2.4 GHz: 2400 MHz ~ 2482 MHz 5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz
Transmit Power	Up to 23 dBm on 2.4 GHz Up to 25 dBm on 5 GHz (Maximum power is limited by regulatory domain)
Radio Chains	2 × 2:2
SU-MIMO	Two (2) spatial stream Single User (SU) MIMO for up to 574 Mbps wireless data rate with HE40 bandwidth to a 2×2 wireless client device under the 2.4GHz radio. Two (2) spatial stream Single User (SU) MIMO for up to 1,200 Mbps wireless data rate with VHT80 to a 2×2 wireless device under the 5GHz radio.
MU-MIMO	Two (2) spatial streams Multiple (MU)-MIMO up to 1,200 Mbps wireless data rate for transmitting to two (2) streams MU-MIMO 11ax capable wireless client devices under 5GHz simultaneously. Two (2) spatial streams Multiple (MU)-MIMO up to 574 Mbps wireless data rate for transmitting to two (2) streams MU-MIMO 11ax capable wireless client devices under 2.4GHz simultaneously.
Supported Data Rates	802.11ax: 2.4 GHz: 9 to 574 (MCS0 to MCS11, NSS = 1 to 2) 5 GHz: 18 to 1200 (MCS0 to MSC11, NSS = 1 to 2) 802.11b: 1, 2, 5.5, 11 802.11a/g: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5 to 300 Mbps (MCS0 to MCS15) 802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)
Supported Radio Technology	802.11ax: Orthogonal Frequency Division Multiple Access(OFDMA) 802.11a/g/n/ac: Orthogonal Frequency Division Multiple (OFDM) 802.11b: Direct-sequence spread-spectrum (DSSS)
Channelization	802.11ax supports high efficiency throughput (HE) —HE 20/40/80 MHz 802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz 802.11n supports high throughput (HT) —HT 20/40 MHz 802.11n supports high throughput under the 2.4GHz radio –HT40 MHz (256- QAM) 802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU
Supported Modulation	802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM 802.11b: BPSK, QPSK, CCK
Max Concurrent User	128 per radio
Environmental & Physical
Operating Temperature	-4º~140ºF/-20ºC~60ºC
Storage Temperature	-40Fº~176ºF/-40ºC~80ºC
Storage Humidity	Storage: 90% or less
IP Rating	IP67
Surge Protection	1KV ESD Protection Contact: 4KV Air: 8 K
Dimensions & Weight
Weight	720 g
Dimensions	190x 124 x 47 mm
Package Contents	1 – EWS850-FIT Outdoor Access Point 2 – Pole-Mounting Brackets 1 – Wall-Mount Screw Set 2 – 2.4GHz 5dBi SMA Antennas 2 – 5GHz 5dBi SMA Antennas 1 – Quick Installation Guide 1 – EPA5006GR PoE Injector
Compliance
Safety Compliance	CB
WEEE	Yes
RoHS	Yes
Regulatory Compliance	FCC CE IC UKCA
