| HARDWARE |
| Mobile |
5G Sub-6Ghz SA/NSA 2.4/3.4Gbps DL (4×4 MIMO), 900/550 Mbps UL (2×2); 4G (LTE) – LTE Cat 20 2.0Gbps DL, 210Mbps UL; 3G – 42 Mbps DL, 5.76Mbps UL |
| CPU |
Mediatek, Dual-core, 1.3 GHz, ARM Cortex A53 |
| RAM |
512MB DDR3 |
| Storage |
16MB serial NOR flash, 512MB serial NAND flash |
| Powering options |
4-pin industrial DC power socket, 9 – 50 VDC |
| SIM |
2 x SIM slots (Mini SIM – 2FF), 1.8 V/3 V, external SIM holders, eSIM (Optional) |
| Antenna connectors |
4 x SMA for Mobile, 3 x RP-SMA for Wi-Fi, 1 x SMA for GNSS |
| Ethernet |
5 x RJ45 ports, 10/100/1000 Mbps |
| WiFi |
802.11b/g/n/ac/ax (Wi-Fi 6) with data transmission rates up to 2402Mbps on 5GHz, 576Mbps on 2.4GHz (Dual Band, MU-MIMO) |
| GNSS |
GPS, GLONASS, BeiDou, Galileo and QZSS |
| Inputs/Outputs |
1 x Digital Input, 0 – 6 V detected as logic low, 8 – 50 V detected as logic high, 1 x Digital Output, Open collector output, max output 50 V, 300 mA |
| Other |
1 x USB A port for external devices, 1 x Grounding screw |
| Status LEDs |
4 x WAN status LEDs, 3 x Mobile connection type, 3 x Mobile connection strength, 8 x LAN status, 1 x Power, 2 x 2.4G and 5G Wi-Fi, 2 x WAN status |
| Operating temperature |
-40 °C to 75 °C |
| Housing |
Anodized aluminum housing and panels |
| Dimensions (W x H x D) |
130.4 x 42.6 x 103.4 mm |
| Weight |
452 g |
| SOFTWARE |
| Operating system |
RutOS (OpenWrt based Linux OS) |
| Mobile features |
SIM switch, Status, SMS, USSD, Black/White list, Multiple PDN, Band management, APN, Bridge, Passthrough, Framed routing |
| Network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| VPN and tunneling |
OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard, Tinc, Tailscale |
| Monitoring and Management |
WEB UI, FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, RMS |
| Cloud solutions |
RMS, FOTA, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx |
| Hotspot |
Captive portal (Hotspot), internal/external Radius server, SMS authorization, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes |
| GNSS |
GPS, GLONASS, BeiDou, Galileo and QZSS |
