Thiết bị Switch EnGenius ECS2510FP

0 trên 5 dựa trên 2 đánh giá

Tình trạng: In stock

Liên hệ báo giá: 0979.300.098

Hàng chuẩn hãng, bảo đảm nguồn gốc rõ ràng.
Hỗ trợ tư vấn dự án và giải pháp miễn phí.
Đồng hành cùng đại lý và các gói dự án lớn nhỏ.
Cung cấp chứng từ CO/CQ đầy đủ, minh bạch.
Dịch vụ bán hàng online nhanh chóng, giao hàng toàn quốc.
Hỗ trợ kỹ thuật chu đáo, sẵn sàng đồng hành cùng khách hàng.

Description
Reviews (0)

Thông số kỹ thuật

Mục	Chi tiết
Port Standards	802.3 10BaseT 802.3u 100BaseT 802.3ab Gigabit Ethernet 802.3bz 2500Base-T Ethernet 802.3x Full-Duplex Flow Control
Network Ports	(8) 10/100/1000/2500 Mbps Ports (2) SFP+ Ports
Switching Capacity	120Gbps
SDRAM	512MB
Flash Memory	128MB
PoE Capable Ports	1–8 (802.3at/af)
Total PoE Budget	240W
Power Source	100 ~ 240VAC, 50-60Hz
Physical Interface
LED Indicators	Power LED Fault LED PoE Max LED LAN Mode LED PoE Mode LED
Ports	Link/Activity/Speed (per Ethernet port) Link/Activity/Speed (per SFP slot)
Software Features (L3)
Multiple IP Interface	20 IPv6 address
ARP Table	Max. 192 ARP entries
Static ARP	Static 192 ARP entries
IPv4 Static Route	Max. 63 entries
IPv6 Static Route	Max. 21 entries
Software Features (L2)
Network Management	EnGenius Cloud SkyKey ezMaster Local Web GUI
MAC Address Table	16K
Jumbo Frame	9K
Multicast Group	Max 256 groups
MLD Snooping	v1
QoS (Priority Queues)	8 Queues
Trust Mode	CoS/802.1p DSCP CoS/802.1p-DSCP
Scheduling Mechanism	Strict / WRR / Strict + WRR
Bandwidth Control	Port-based (Ingress/Egress)
Port Security	Max. 256 Entries
ACL	MAC Based ACL IPv4/IPv6 Based ACL ACL Binding Time-based ACL
Web GUI	HTTP IPv4/IPv6 HTTPS IPv4/IPv6
SSL Certificate	Certificate/Key Import
SNMP	v1/v2c/v3
RMON	1,2,3,9
System Time	Time Setting / Daylight Saving
Common L2 Features	802.1d Spanning Tree Loopback Detection Multicast Filtering IGMP Forwarding IGMP Snooping MLD Forwarding 802.1Q VLAN 802.3x Flow Control 802.3ad Link Aggregation IPv4 DHCP Relay IPv4 DHCP Snooping Source MAC Check-up ARP Inspection ARP Validation Voice VLAN Port/Protocol-based VLAN CoS Mapping 802.1X Radius Authentication IPv4/IPv6 Settings EEE (802.3az) CLI SSH Telnet TFTP Client Upgrade/Backup SNTP SYSLOG
Environmental & Physical
Temperature Range	0°C – 50°C (32°F – 122°F)
Humidity	5% – 95% (non-condensing)
Package Contents	1x Cloud Managed Gigabit Switch 1x Quick Installation Guide 1x Power Cord 1x RJ45 Console Cable 1x Rack Mount Kit
Dimensions & Weight	Weight: 2.6 kg (5.7 lbs) Width: 330 mm (12.99”) Length: 230 mm (9.05”) Height: 44 mm (1.73”)
