Thông số kỹ thuật
Feature | Specification |
Switching capacity | 20 Gbps |
Forwarding capacity | 15 Mpps |
CPU | 1 Core, 800MHz |
Flash/SDRAM | 256MB / 512MB |
Dimensions (W × D × H) | 266 × 161 × 43.6 mm |
Weight | ≤ 1.5 kg |
Management port | 8 × 10/100/1000TX + 2 × SFP |
Maximum Stacking bandwidth | 16 Gbps |
Maximum stacking num | 9 |
Port Surge | 6KV |
Input voltage | AC: 100V – 240V, 50/60Hz |
Total power consumption | MIN: 8W (AC)MAX: 15W (AC) |
Fan number | Fan-less |
MTBF (Year) | 140.82 |
MTTR (Hour) | 1 |
Operating temperature | -5℃ ~ 50℃ (normal)-5℃ ~ 45℃ (module < 80km)-5℃ ~ 40℃ (module ≥ 80km) |
Storage temperature | -40℃ ~ 70℃ |
Relative humidity (non-condensing) | 5% RH – 95% RH |
