Máy tính công nghiệp Darveen NBC-2360 Intel® Elkhart Lake Celeron®/Tiger Lake Core™ i5 Fanless Box Computer with 6x COM,6x USB, 2x LAN

0 trên 5 dựa trên 2 đánh giá

(Có 0 đánh giá)

Mã sản phẩm: Darveen NBC-2360 Tình trạng: In stock

Liên hệ báo giá: 0979.300.098

Thông số kỹ thuật

System
CPU	Intel® Celeron® J6412 processor	Intel® Core™ i5-1155G7 processor
CPU TDP	10W	12W
Memory	1x DDR4 3200 MHz SO-DIMM up to 32GB
Storage	1x M.2 2280 NVME
BIOS	AMI UEFI
Watchdog Timer	Software programmable supports 256 levels system reset
I/O Ports
USB	2x USB 2.0, 4x USB 3.0
Serial	6x COM (2x RS-232/485)
Ethernet	2x RJ45 GbE Intel® I210AT
Display	1x HDMI, 1x VGA
SIM Card Slot	1x SIM card slot (inside)
Antenna	3x SMA antenna holes
Expansion Slot
Mini PCIe	1x Full length Mini PCIe
M.2	1x M.2 2280 NVME
RF Communication
Wi-Fi	Mini PCIe expansion (optional)
Cellular	Mini PCIe expansion (optional)
Bluetooth	Mini PCIe expansion (optional)
GNSS	Mini PCIe expansion (optional)
Audio
Audio	Mic in, line out
Power
Button	Yes
DC Input	9-36VDC	12VDC
Power Mode	AT/ATX
Operating System
Windows	Windows 10
Linux	Ubuntu
Mechanical
Dimensions (W x D x H)	160x 135.4x 60mm (6.3 x 5.33 x 2.36 inches)
Weight (N.W.)	2 kg (4.41 lbs)
Mounting	Wall mount
Material	Aluminum alloy
Environment
Operating Temperature	-10 to 60℃ (14 to 140°F)
Storage Temperature	-20 to 60℃ (-4 to 140°F)
Relative Humidity	10% to 95% @ 40°C (104°F), non-condensing
Certification
EMC	CE, FCC Class A
